Name: G42-1200 73.90/98.00mm 10+0 blades Turbocharger milling/aluminum 2618/billet compressor wheel
Brand: Max Able Auto Parts Co.,Ltd.
SKU: G42-1200
Availability: InStock

Home Products Billet compressor wheel

G42-1200 73.90/98.00mm 10+0 blades Turbocharger milling/aluminum 2618/billet compressor wheel

Product Details:

Brand Name:	NO
Model Number:	G42-1200

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Packaging Details:	neutral packing
Delivery Time:	3-7 days
Payment Terms:	TT ,western union ,paypal
Supply Ability:	1000

Contact Now

Detailed Product Description

Size:	73.90/98.00mm	Type:	Turbochargers

1. MODEL:G42-1200 forward

2.G42-1200 73.90/98.00mm 10+0 blades Turbocharger milling/aluminum 2618/billet compressor wheel

3.Size:

Nose diameter:15.20mm

Inducer:73.90mm

exducer:98.00mm

Tapered tip exducer:102.90mm

Tip height:10.11mm

Superback:5.68mm

Overall height:65.14mm

bore size :8.25mm

Bore type:Threaded-M8x1.25LHT

Trailing angle:35 degree

Cutback:11.6mm

SP Height angle:0.00

Blades height:50.50mm

Splitter height:0.00mm

10+0 blades

forward rotation

Tapered tip angle:16.2 degree

It is custom size,please check carefully before buying

4.High quality and competitive price.

5.if you want more details, please send email to me.

All the compressor wheels have been balanced.

Skype: maxabledieselparts

Wechat/Whatsapp:+86-18018657719

G42-1200 73.90/98.00mm 10+0 blades Turbocharger milling/aluminum 2618/billet compressor wheel
