| Model Number: | RHV4 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Packaging Details: | neutral packing |
| Delivery Time: | 3-7 days |
| Payment Terms: | TT ,western union ,paypal |
| Supply Ability: | 1000pcs |
| Size: | 36.35/49.00mm | Type: | Turbochargers |
|---|
1.Model:RHV4 Forward
3.Size:
Nose diamter:9.97mm
inducer:36.35mm
Exduder:49.00mm
Tapered tip exducer:52.90mm
Tip height:4.38mm
Superback:3.85mm
bore size :5.09mm
bore type:through
Overall height:29.60mm
Trailing Angle:45 degree
Cutback:3.0
SP height angle:0.00
Blades height:22.30mm
Splitter height:11.45mm
It is for OE compressor housing.
6+6blades
Forward rotation
Tapered tip angle:30 degree
4.High quality and competitive price.
5.if you want more details, please send email to me.
We can produce as your requirement.
THE MINIMUN ORDER IS 5PCS
The more models we also have.
ALL The billet compressor wheels have been balanced.
