| Brand Name: | NO |
| Certification: | ISO |
| Model Number: | RHF3 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Packaging Details: | neutral packing |
| Delivery Time: | 3-7 days |
| Payment Terms: | TT ,western union ,paypal |
| Supply Ability: | 1000pcs |
1.Model:RHF3 Forward
3.Size:
Nose diamter:8.50mm
inducer:34.24mm
Exduder:45.00mm
Tapered tip exducer:47.80mm
Tip height:3.42mm
Superback:1.06mm
Overall height:21.40mm
bore size :4.41mm
Trailing angle:70 degree
Cutback:3.0
Blades height:18.50mm
SP height angle:0.00
Splitter height:9.70mm
6+6 blades
forward rotation
Tapered tip angle: 30 degree
It is custom size ,please check carefully before buying.
4.High quality and competitive price.
5.if you want more details, please send email to me.
We can produce as your requirement.
All the billet compressor wheels have been balanced.
The more models we also have.
