K04 5306-123-2007 43.03/56.08mm 11+0 blades performance Billet/milling compressor wheel for 5304-970-0054/0035/0043/0045

Brand Name:	NO
Model Number:	K04

Contact Now

Detailed Product Description

Size:	43.03/56.08mm	Type:	Turbochargers

1. MODEL:K04 FORWARD

2.K04 43.03/56.08mm 5306-123-2007 11+0 blades high performance Billet/milling compressor wheel for 5304-970-0054/0035/0043/0045/0051

3.Size:

Nose diameter:9.90mm

Inducer:43.03mm

exducer:56.08mm

Tapered tip exducer:60.04mm

Tip height:4.43mm

Superback:1.80mm

bore size :4.61mm

Overall height:27.70mm

Trailing Angle:60

Cutback:0.0

Tapered tip Angle:30 degree

Blade height:24.04mm

11+0 blades forward

Fit for OE compressor housing

4.High quality and competitive price.

5.if you want more details, please send email to me.

All the compressor wheel have been balanced.
