| Model Number: | TD05H 20G |
| Minimum Order Quantity: | 1PC |
|---|---|
| Packaging Details: | neutral packing |
| Delivery Time: | 3-7 days |
| Payment Terms: | TT ,western union ,paypal |
| Supply Ability: | 1000pcs |
1. MODEL:TD05H 20G forward
2.TD05H-20G 52.56/68.01mm 49179-43400 6+6 blades high performance high blade height Turbo Billet/milling/aluminum 2618 compressor wheel
3.Size:
Nose diameter:12.40mm
Inducer:52.56mm
Exducer:68.01mm
Tapered tip exducer:73.05mm
Tip height:5.37mm
Superback:2.90mm
Overall height:36.40mm
bore size :6.50mm
bore type:through
Trailing angle:55
Cutback:-10.0
Blade height :34.88mm
Splitter height:23.25mm
Sp height angle:-10.80
6+6 BLADES.
Forward rotation
Tapered tip angle:30 degree
It is for custom size ,please check carefully before buying
4.High quality and competitive price.
5.if you want more details, please send email to me.
All the compressor wheels have been balanced.
